Product Details:
Payment & Shipping Terms:
|
| Laser: | Q Switched Nd Yag Laser | Wavelength: | 1064nm 532nm 1320nm |
|---|---|---|---|
| 1064nm: | Pigmentation Removal And Tattoo Removal | 1320nm: | Carbon Peeling Skin Lightening |
| 532nm: | Tattoo Removal And Skin Rejuvenation | Cooling: | Air Cooling And Water Circle Cooling |
| High Light: | portable laser tattoo removal machine,laser tattoo removal device |
||
q switched nd yag laser tattoo removal / tattoo removal laser / Laser tattoo removal machine
Machine numb er : Q laser
Application :
1 . Tattoo removal ,
2 . Birth mark removal ,
3 . Red and brown pigment
4 . Eliminate Coffee spot and Taitian naevus
5 . eyebrow-cleaning and eyeline-cleaning
How does tattoo removal laser woking
The certain wavelength laser(1064nm , 532nm,1320nm ) effect on treatment areas ,
the abnormal pigmentations will absorb the accumulated powerful laser energy by the Q switch , parts of them will break up into tiny particles and come out of epidermis at once ,
the others will be licked up by macrophage , then be eliminated from body as the metabolish . Then pigments become ligther and lighter till be fully removed .
Handle and wavelength
One piece handl with three tips
The laser has three wavelengths : 1064 nm & 532nm and 1320nm .
The 1064nm is for treatment of the color in blue or black pigmentation of the skin ;
The 532nm is for treatment of the color in red and brown pigmentation of the skin .
The front-end of laser handpiece for the 1064 nm wavelength is the round one, while for the 532nm wavelength is the square one .
The black is the 1320nm for carbon peeling skin rejuvenation and skin lightening .
Features :
1 Long working
2 Very short pulse width 5-7ns , compare it with the common tattoo removal laser 10ns , its output energy is more powerful , more short pulse width ,more better treatment result
Fast to removal pigments and tattoos
3 Painless
4 High laser energy
5 Long life ( more than 500,000 shots )
6 With 1320nm tips for skin rejuvenation
| Wavelength | 1064nm & 532nm , 1320nm |
| Spot Diameter | 1~5mm |
| Width of Pulse | 5-7ns |
| Pulse Energy | 200－1000mj |
| Repetition Rate | 1-6Hz adjustable |
| Operation Interface | 6” Dual button screen |
| Cooling Systems | Air Cooling & Close Water Circulation |
| Electrical Requirements | 100/110V,50~60HZ or 230~260V, 50~60HZ |
| Dimension | 41×24×30 cm |
| Net Weight | 14 kg |
| Package size | 54×35×45 cm |
| Gross weight | 18 KG |
Treatment picture :
Warranty & After-sale Service & Training
A . 2 years ex factory under normal and Correct operation ; free labor and material but without consumables parts.(since our great confidence of our machine’ s excellent quality
B . In order to give clients more satisfied products experience, the stuff with rich experience of laser beauty and medical knowledge, and they work in this area for 2-5 years. And for our after-sales department , they work for 7 days for a week and 18-24 hours a day to ensure the 24 hours on line service .
C . There is a copy user’s manuals and clinical treatment guider for detailed instructions on the introduction, the operation , the maintenance , etc .
D . There is a comprehensive training last for 5-7 days through email , vedio ,on line service , including how to operate, maintenance and adjust the treatment parameters for different treatments , etc .
